| Channel Specifications | ||
| Max. Channels | 16 vibration/temp, 1 speed, 2 processing | |
| Vibration (Temperature optional) | ||
| Sensor Integrated | IEPE acceleration sensor | High/low frequency synchronous acquisition |
| Input Impedance | 200kΩ | - |
| A/D Converter | 24 bits delta-sigma ADC | - |
| Frequency Response | 0.2dB (10Hz ~ 5kHz) / 0.6dB (2Hz ~ 20kHz) | - |
| Temperature Range | -40ºC ~ 120ºC (±2ºC precision) | - |
| Speed & Sway Channels | ||
| Speed Sensor | TTL isolation, 12V non-isolated, 24V PLC | 0 ~ 20000 RPM range |
| Sway Channel | RH123 sensor support (Two axial) | 0~5V Signal range |
| Signal Processing | ||
| Waveform Length | 2M samples/CH | - |
| Spectrum Lines | 400 to 102400 lines | - |
| Environmental & Power | ||
| Dimension/Weight | 400mm×300mm×110mm / <5kg | IP65 Grade |
| Power Supply | Outdoor: 220VAC | Indoor: 12-24VDC | Consumption: <8W |
