Basic Specifications
Principle of Work
Vector Control Transducer
Voltage Supply
Low Voltage Variable-Frequency Drive
Link of Transformation
AC-DC-AC VFD
High Performance Vector VFD
The LX3300 series inverter is based on a DSP control system, adopts vector control technology, and is combined with various protection methods. It can be used for asynchronous motors to improve their driving performance. It integrates position, speed, and torque control, supports customer secondary development, meets personalized and industry needs, is flexible in application, and has stable performance.
Core Functions
✓
Vector control technology
✓
0.4-37KW standard built-in brake unit
✓
Support common DC bus scheme
✓
Support multiple encoding options
✓
Integrated position & speed control
✓
Integrated torque control
✓
Closed loop vector control 0HZ 200% torque
✓
Standard RS485 communication
Industrial Applications
⚡
Textile & Paper Machinery
⚡
Metal & Woodworking Processing
⚡
Printing & Plastic Machinery
⚡
Petroleum & CNC Machinery
Technical Model Parameters
| Model |
Power Capacity (KVA) |
Input Current (A) |
Output Current (A) |
Motor (KW) |
| 3300-0R7G-4 | 1.5 | 3.4 | 2.1 | 0.75 |
| 3300-1R5G-4 | 3 | 5 | 3.8 | 1.5 |
| 3300-2R2G-4 | 4 | 5.8 | 5.1 | 2.2 |
| 3300-004G-4 | 5.9 | 10.5 | 9 | 4 |
| 3300-5R5G-4 | 8.9 | 14.6 | 13 | 5.5 |
| 3300-7R5G-4 | 11 | 20.5 | 17 | 7.5 |
| 3300-011G-4 | 17 | 26 | 25 | 11 |
| 3300-015G-4 | 21 | 35 | 32 | 15 |
| 3300-022G-4 | 30 | 46.5 | 45 | 22 |
| 3300-045G-4 | 69 | 92 | 91 | 45 |
| 3300-090G-4 | 134 | 180 | 176 | 90 |
Product Gallery
Frequently Asked Questions
What are the available payment terms?
We accept T/T, L/C, Western Union, PayPal, and Cash.
What is the typical delivery time?
For an order of approximately 2000 units, the delivery time is usually 10-15 days.
What is your annual production capacity?
We have the capacity to manufacture up to 400,000 sets of inverters per year.
Which international markets do you serve?
Our products are shipped globally, including Europe, the Middle East, South America, Asia, and Africa.
What certifications do your products hold?
Our products are compliant with ISO and CE certification standards.
Do you support OEM business partnerships?
Yes, we provide comprehensive OEM services to meet specific branding and functional requirements.
